Pulping equipment




The Vokes Rotor of D-hydrapulper deviates from the center, thus pulp stock has a more rapid and frequent contact with the rotor. A unhindered rotational flow can be produced and the paper stock move towards the central rotor in a spiral line from the fed site when using the traditional Hydrapulper, while D-type hydrapulper changes this flow pattern so that the paper stock can be contracted with the rotor more rapidly, thus shortening the time from the addition of paper stock to the degradation and improving the production capacity without increasing the power and volume.

D-hydrapulper is provided with wire stranding machine and sediment trap, and the wire stranding machine can remove the twining impurities, such as plastic bags, rope heads, iron wires, etc. It is recommended that the type of wire stranding machine is ZTS1, there is a rectangular interface on its tank bottom, the sediment trap is connected by this interface, and the plastic foam and other light impurities are removed by impurity separator to achieve the continuous production, while the heavy impurities are sedimented on the bottom of sediment trap and then are discharged regularly. This interface can also be provided only with the heavy residue collecting tank to achieve the batch production.

Technical parameters of D-hydrapulper:

Model                     ZDSD25   ZDSD26   ZDSD27   ZDSD28   ZDSD29   ZDSD30   ZDSD31   ZDSD32   ZDSD33   ZDSD34   ZDSD35  ZDSD36

Nominal volume (m³)           15         20      25         30        35        40       50        60        70       90        120       135

Processing capacity(%)         3-5

Production capacity(T/D)      80-120    140-180  180-230     230-280   260-330   300-380   370-450   460-550   550-650  650-800  800-1100  1100-1500

Motor power (KW)              160      185      220         280       315       355       450       560      630      800      1000      1120
